0Cr19Al3 Alloy Wire for Electrolysis Hydrogen Production

0Cr19Al3 Alloy Wire for Electrolysis Hydrogen Production

Nome da marca:	DLX
Número do modelo:	Fio de liga FeCrAl 0Cr19Al3
MOQ:	10kg
Condições de pagamento:	L/C,D/A,D/P,T/T,Western Union
Capacidade de abastecimento:	500 toneladas por mês

Informações pormenorizadas

Descrição do produto

Informações pormenorizadas

Lugar de origem:

China, Jiangsu

Certificação:

Ce,Rohs

Habilidade da fonte:

500 toneladas por mês

Destacar:

0Cr19Al3 alloy resistance wire

electrolysis hydrogen production wire

high-temperature resistant alloy wire

Descrição do produto

0Cr19Al3 Alloy Wire for Electrolysis Hydrogen Production

0Cr19Al3 FeCrAl Wire is a high-performance FeCrAl alloy containing 19% chromium and 3% aluminum, providing exceptional resistance to oxidation and corrosion. These properties are crucial in harsh electrolytic environments where the wire is exposed to high temperatures and corrosive electrolytes. The wire's stable electrical resistance and excellent heat resistance ensure reliable long-term performance, maximizing efficiency in hydrogen production processes.

Primarily used as electrode material in electrolysis systems, 0Cr19Al3 Alloy Wire facilitates water molecule separation into hydrogen and oxygen. It minimizes energy loss, optimizes the electrolysis process, and significantly enhances overall hydrogen generation efficiency.

Parameter Comparison Table

Alloy Nomenclature Performance	1Cr13Al4	0Cr25Al5	0Cr21Al6	0Cr23Al5	0Cr21Al4	0Cr21Al6Nb	0Cr27Al7Mo2
Chemical Composition (%) - Cr	12.0-15.0	23.0-26.0	19.0-22.0	20.5-23.5	18.0-21.0	21.0-23.0	26.5-27.8
Chemical Composition (%) - Al	4.0-6.0	4.5-6.5	5.0-7.0	4.2-5.3	3.0-4.2	5.0-7.0	6.0-7.0
Chemical Composition (%) - Re	Opportune	Opportune	Opportune	Opportune	Opportune	Opportune	Opportune
Chemical Composition (%) - Fe	Rest	Rest	Rest	Rest	Rest	Rest	Rest
Max. Continuous Service Temp. of Element (°C)	950	1250	1250	1250	1100	1350	1400
Resistivity at 20°C (μΩ.m)	1.25	1.42	1.42	1.35	1.23	1.45	1.53
Density (g/cm³)	7.4	7.1	7.16	7.25	7.35	7.1	7.1
Tensile Strength (N/mm²)	580-680	630-780	630-780	630-780	600-700	650-800	680-830
Elongation at Rupture (%)	>16	>12	>12	>12	>12	>12	>10

Available Shapes and Sizes

Shape	Size (mm)
Wire	0.05-7.5
Rod	8-50
Ribbon	(0.05-0.35)*(0.5-6.0)
Strip	(0.5-2.5)*(5-180)

Key Features

Exceptional Oxidation and Corrosion Resistance: High chromium (19%) and aluminum (3%) content provides superior protection in harsh electrolysis conditions.
Stable Electrical Resistance: Maintains consistent electrical resistance for efficient energy transfer and reduced energy consumption.
High Thermal Stability: Withstands temperatures up to 1,500°C, ideal for high-temperature electrolysis applications.
Durability and Longevity: High resistance to thermal stress and corrosion ensures long service life and reduced downtime.
Customizable Dimensions: Available in various diameters and lengths to meet specific electrolysis system requirements.

Advantages of Using DLX's 0Cr19Al3 Alloy Wire

Improved Electrolysis Efficiency: Stable electrical properties and heat resistance ensure optimal system operation, reducing energy waste.
Cost-Effective Long-Term Solution: Durability reduces replacement frequency, lowering maintenance costs.
Increased System Lifespan: Oxidation and corrosion resistance maintains performance over extended periods.
Reliable Quality: Strict quality control ensures consistent performance meeting industry standards.
Eco-Friendly and Sustainable: Supports green hydrogen production to reduce carbon emissions and promote renewable energy.

Industry Analysis

The hydrogen economy is rapidly expanding as industries and governments seek to decarbonize energy systems. Green hydrogen produced via electrolysis is critical for transportation, power generation, and industrial processes requiring clean, reliable energy.

As demand for green hydrogen increases, electrolysis systems are scaling up, creating need for high-performance materials like 0Cr19Al3 Alloy Wire to ensure system longevity, efficiency, and reliability. Growing interest in clean hydrogen and advancing electrolysis technologies position this alloy wire as essential for the hydrogen production industry.

Applications

Hydrogen Production via Electrolysis: Primary use as electrode material in water electrolysis cells.
Fuel Cells: Provides necessary conductivity and durability for hydrogen-to-electricity conversion.
Energy Storage: Enhances efficiency of hydrogen production systems for clean energy storage.
Industrial Hydrogen Production: Used in chemical production, petroleum refining, and ammonia synthesis.
High-Temperature Applications: Ideal for heat exchangers and reactors due to thermal stability.

DLX's Competitive Advantage

DLX Corporation leads in providing high-performance materials for energy innovation industries. Choosing 0Cr19Al3 Alloy Wire selects a durable, efficient solution for hydrogen production needs, designed to enhance electrolysis system performance and lifespan.

Why Choose DLX?

Industry Expertise: Years of experience supplying high-quality materials for hydrogen and clean energy sectors.
Rigorous Quality Control: Every batch undergoes strict testing to ensure highest performance standards.
Cost-Efficiency: Improves system efficiency and longevity, offering long-term savings.
Sustainability Commitment: Dedicated to supporting clean energy transition through green hydrogen production materials.

Frequently Asked Questions

What makes 0Cr19Al3 Alloy Wire ideal for electrolysis?
High chromium and aluminum content provides excellent oxidation and corrosion resistance, while thermal stability ensures reliable high-temperature performance.
How does 0Cr19Al3 Alloy Wire improve electrolysis efficiency?
Maintains stable electrical resistance, reducing energy losses and improving hydrogen production efficiency.
What is the maximum temperature 0Cr19Al3 Alloy Wire can withstand?
Withstands temperatures up to 1,500°C, suitable for high-temperature electrolysis applications.
Is 0Cr19Al3 Alloy Wire customizable?
Yes, DLX offers customizable wire diameters and lengths to suit specific electrolysis system requirements.
How long does 0Cr19Al3 Alloy Wire last in electrolysis systems?
Corrosion and oxidation resistance ensures long service life, reducing replacement frequency.
Can this wire be used in other applications besides electrolysis?
Yes, also used in fuel cells, energy storage systems, and other high-temperature industrial applications.
What makes DLX's 0Cr19Al3 Alloy Wire stand out?
Rigorous quality testing ensures highest performance standards and reliable long-term results.
How is the global hydrogen market expected to grow?
The hydrogen economy is expanding rapidly, driven by clean energy demand, with electrolysis as a key method for large-scale hydrogen production.
